Sugatsune Stainless Steel Cruciform Mounting Plate

Our Sugatsune Stainless Steel Cruciform Mounting Plate is compatible with our range of Stainless Steel Hinges (below). The 3 way adjustment, allows the hinge to be positioned perfectly.

The products Specification sheet can be found at the bottom of this page, please read for installation guidance. Please click here to view our Help Guides & Advice page.





Specifications



• Plate Height: 0mm
• Fixing Centres: 37 x32mm
• Fixing Method: Euro Screws
• Finish: Stainless Steel (304)
• Suppliers Code: 100-P4A-32-3W-SUS304B





Compatible Products

Stainless Steel Clip On Hinge - 100 Degree Opening - 3/4 Overlay - Sugatsune

Stainless Steel Clip On Hinge - 100 Degree Opening - Full Overlay - Sugatsune

Stainless Steel Clip On Hinge - 100 Degree Opening - Half Overlay - Sugatsune

Stainless Steel Un-Sprung Clip On Hinge - 100 Degree Opening - 3/4 Overlay - Sugatsune

Stainless Steel Un-Sprung Clip On Hinge - 100 Degree Opening - Full Overlay - Sugatsune



Recommended Screws

Stainless Steel Pozi Countersunk Screw 4 x 16mm (8 x 5/8")
