IntAfit Blind Corner Soft Close Hinge 105° On 35mm Cup Diameter

Our IntAfit Soft Close hinge for Blind Corner cabinets should be used when there is no cabinet side to fix to as the mounting plate fixes to the inside face of the cabinet.

Opening to either 95° or 105°, this hinge gives you full access to the cabinet when the door is open, while ensuring a tight fit to the cabinet face when the door is closed.

The Soft Close feature of the hinge prevents the cabinet door from slamming when closing.

Blind Corner hinges are used by most kitchen manufacturers however, they are also suitable for bedroom, bathroom and office projects. The euro screws on the hinge, allow height, depth and side movement to ensure the door is a perfect fit when closed.



Please click here to view our Help Guides & Advice page





Specifications



• Overlay Adjustment: +/- 3mm
• Depth Adjustment: +/- 2mm
• 2 x Option Opening Angle: Can be opened to either 95 or 105 degrees
• Door Thickness: 14 - 22mm
• Side Thickness: N/A
• Cup Diameter: 35mm
• Hole Centres: 48mm
• Hinge Type: Clip-On
• Material: Steel
• Hinge Finish: Nickel Plated
• Self Closing: Yes
• Soft Closing: Yes
• Adjustment: 3 way
• Plate: 0mm Cam Adjustable
• Pack Contents: 2 Hinges, 2 Plates





Tools & fittings for the job

35mm hole cutter

Torq-Fix Pozi Countersunk Screw 4 x 16mm (8 x 5/8") Zinc
