Sugatsune Low Profile Lid Stay - Stainless Steel 304

Our Sugatsune Low Profile Lid Stay is designed for compact spaces but strong enough to hold the lid/door in the fully open position. To release, simply lift the door slightly and the stay will then allow the door to close. Made from 304 Stainless Steel, this stay is suitable for outdoor use, ideal for use on camper vans, boats and outdoor storage boxes.

Please use the calculation on the products Specification Sheet to check suitability for your application. Please click here for our Torque Calculator Page.



The products Specification sheet can be found at the bottom of this page, please read for installation guidance. Please click here to view our Help Guides & Advice page







Specifications



• Suitable For: Lift up flaps/doors
• Fixing: Side panel mounting
• Opening Angle: Up to 90°
• Designed To: Support the flap in the open position
• Release: Lift to release
• Handed: Non-handed
• Load Capacity: 15kg (please use the calculation in images to check suitability)
• Material: Stainless Steel (SUS304)
• Screws: Not included
• Supplier Code: L-200P





Recommended Screws

Stainless Steel Pozi Countersunk Screw 4 x 16mm (8 x 5/8")



Recommended Bracket

Stay Bracket For Sugatsune Low Profile Lid Stay - Stainless Steel
