Front Mounted Locking Handle - Lock In (Closed Position Only) - Stainless Steel
Our Front Mounted Locking Handle is suitable for our 56mm and 76mm heavy duty ball bearing drawer slides range. This locking handle allows the user to lock a custom built drawer in the closed position and is suitable for drawers with a width of up to 1122mm.
Suitable for a wide range of applications such as: Pick up pull-out platforms, vehicle under floor storage, large product stillage drawers and pull-out access for generators/batteries as well as bespoke engineering projects
Specifications
- Material: PBT + Glass Fiber Handle; Stainless Steel Parts
- Function: Lock-in
- Drawer Width: Up to 1122mm
- Rod Length: 500mm
- Rod Diameter: 10mm
- Max Drawer Front Panel Thickness: 7mm
- Cycle Approved: 30,000 cycles
- Lightweight and Corrosion-resistant for fuel efficiency and outdoor use.
Set Includes
- 1 x Locking Handle (DS91500YL)
- 2 x Stainless Steel (Length: 500mm, Diameter: 10mm) Rods For Drawer Width (DS91500YL)
- 1 x Pair of Locking Blocks (DS91002)
More Locking Points?
Additional locking points can be placed through purchasing our locking blocks separately here.
Require Lock in and Out
To view our lock in (closed position) and out (open position) handle then please see here.
